BIANCHI E-Arcadex Tourer 12-Speed

MOTOR
Bosch Performance Line CX, 85Nm, Kiox display
BATTERY
Bosch Powertube 500Wh integrated battery
FRAME
e-Arcadex Carbon sizes: 47, 51, 55, 58, 61 – 12×142 mm thru axle – Flat mount 140 disc brake type – Fender compatible
FORK
Full Carbon 1.5″ flat mount, disc brake, thru axle 12x100mm
HEADSET
FSA SMR HS with 1-1/8”
SHIFTERS
SRAM Apex Disc Brake
REAR DERAILLEUR
SRAM Apex XPLR
CRANKSET
FSA E-bike Crankset / 165mm – 170mm – 175mm / Hollow Alloy FSA Alloy 42T
BOTTOM BRACKET
Included in the Drive unit
CHAIN
SRAM Apex
BRAKES
Sram included in the shifter
ROTOR
Sram Paceline, Center lock, 160mm
WHEELS
Velomann, 23-622, profile 24,5mm, 32hole, tubeless ready
REARHUB
Formula RXC-142S road disc , center lock, J-bend, thru axle 12x142mm
FRONTHUB
Formula CL-712 road disc , alloy 32h, center lock, J-bend, thru axle 12x100mm
TIRE
Continental 40-622 Terra Trail
STEM
Velomann, Alloy 6061 , 1 1/4″, raise 0° Ext: 80mm-XS/S, 100mm-M, 120mm-L/XL
HANDLEBAR
Velomann Aluminum 6061, reach 70mm, flare angle 16°, drop cc 120 x size 40cm and 130mm x size 42-44-46cm Size: 400mm-XS/S, 420mm-M/L, 440mm-XL
GRIPS / EXTENSIONS
La Spirale Ribbon cork
SEATPOST
Velomann Alloy shaft, alloy head, 15mm offset, 31,6mm Length: 300mm/XS – SM ; L350mm/MD – LG -XL
SADDLE
Velomann, carbon steel rail, 262×145
